Jib Crane Models
Jib cranes are made up of a trolley hoist on a horizontal load-bearing boom. This boom is attached to a pivoting vertical member and up to 20 feet long. Jib cranes can transport loads between any areas within the boom's arc of rotation. Light duty units are used within warehouses and factories for loads weighing up to 5 tons. The web site BestJibCranes.com features the major kinds of jib cranes as being either mast mounted, free-standing or wall-mounted.
Free Standing
The free-standing jib crane models do not need any support from the building structure and can stand by themselves. The horizontal boom in this specific situation is attached to a pivoting vertical column that is firmly anchored to the building floor. This type of jib crane needs a foundation made of either steel or concrete and is able to rotate a full 360 degrees.
Mast-Type
The mast-type jib cranes feature a vertical column that is supported by pivot points at the top and the bottom that are connected to the building floor and the overhead steel structure. These jib-cranes provide 360 degrees of rotation with the benefit of not requiring the massive foundation needed for free-standing units.
Wall Mounted
The wall-mounted jib cranes offer a horizontal boom which is connected to the wall of a building as opposed to the typical vertical column. These machine provide up to 200 degrees of rotation and are ideal in places where the full 360 degree rotation is not required.
There are two model varieties, depending on how the boom is supported. One of the types uses a tie rod that is connected from above the wall to the boom. The other type supports the boom from below by using a cantilever brace that is attached to the wall too.
